JH21 Series High Speed & High Precision Press

JH21 Series High Speed & High Precision Press

200 USD ($)/Set

Product Details:

X

Price And Quantity

  • 5 Set
  • 500.00 - 1000.00 USD ($)/Set
  • 200 USD ($)/Set

Trade Information

  • 1000 Set Per Month
  • 10 Days

Product Description

Technical details


Model

R

Unit

JH21-25

JH21-45

JH21-60

JH21-80

JH21-125

JH21-160

JH21-200

JH21-250

JH21-315

JH21-400

Nominal capacity

Pe

KN

250

450

600

800

1250

1600

2000

2500

3150

4000

Nominal

SP

mm

3

4

4

5

6

6

6

6

7

8

Slide stroke

S

mm

80

120

140

160

180

200

250

250

250

270

Slide strokes per minute

Fixde

n

Times/min

100

80

70

60

50

45

45

30

30

30

variable


Times/min

60-100

50-80

45-70

40-60

35-50

30-45

25-45

20-30

23-30

23-30

Maximum die set height

H2

mm

250

270

300

320

350

400

450

500

500

550

Die height adjustment

t

mm

50

60

70

80

90

100

110

120

120

120

Throat depth

C1

mm

210

225

270

310

350

400

430

450

450

490

Distance between uprights

d1

mm

450

515

560

610

670

736

910

980

980

1050

Slide bottom size

L x R

a

mm

360

410

480

540

620

700

880

950

950

1020

F x B

b

mm

250

340

400

460

520

580

650

700

700

750

Dia

d

mm

40

50

50

50

70

70

70

70

70

70

Depth

I

mm

65

60

70

65

90

100

100

130

130

130

Bolster size

L x R

C

mm

720

825

930

950

1100

1170

1390

1500

1540

170

F x B

D

mm

400

440

520

600

680

760

840

880

880

950

Blanking hole diameter

ǿ

mm

150

150

150

150

160

180

200

200

200

200

Bolster thickness

H3

mm

80

110

130

140

155

165

180

190

190

210

Bolster surface height

H1

mm

780

800

900

900

900

900

1000

1000

1000

1100

Overall dimension

L x R

A

mm

1496

1585

1540

1765

2040

2305

2600

2660

2720

2850

F x B

B

mm

945

1075

1200

1200

1320

1420

1540

1640

1680

1750

H

H

mm

2120

2391

2570

2725

3035

3215

3800

3865

3865

4150

Distance between foundation bots

F x B

a

mm

980

1075

1100

1210

1430

1665

2020

2100

2140

2260

L x R

b

mm

690

760

840

920

1040

1140

1360

1460

1500

1570

Motor

Model



Y100L-4

Y1325-4

Y1325-4

Y132M-4

Y160-M4

Y160L-4

Y180L-4

Y200L-6

Y225m-6

Y250m-6

Power


KW

3

5.5

5.5

7.5

11

15

18.5

22

30

37

Weight (Approximate


Kg

2450

3550

5150

6450

9550

13600

19200

23200

26600

31600
