Y41 Series Simple Columnar Correction Pressed Hydraulic Press
Product Details:
- Supply Ability : 1000 Set Per Month
200 USD ($)/Set
X
Price And Quantity
- 200 USD ($)/Set
- 5 Set
- 500.00 - 1000.00 USD ($)/Set
Trade Information
- 1000 Set Per Month
- 10 Days
Product Description
Technical Specification.
| Model | Unit | 25T | 40T | 63T | 100T | 160T | 200T | 250T | 315T | 400T | 5OOT | 1500T | |
| Nominal force (kn) | KN | 250 | 400 | 630 | 1000 | 1600 | 2000 | 2500 | 3150 | 4000 | 5000 | 15000 | |
| Max. hydraulic pressure(kN) | Mpa | 21 | 25 | 25 | 25 | 25 | 25 | 26 | 25 | 25 | 25 | 25 | |
| Max. opening height(mm) | mm | 430 | 510 | 550 | 500 | 650 | 900 | 900 | 900 | 900 | 900 | 1000 | |
| Slipper stroke(mm) | mm | 500 | 500 | 500 | 500 | 500 | 500 | 5OO | 500 | 500 | 500 | 500 | |
| Slider descending speed | mm | 35 | 40 | 30 | 24 | 20 | 18 | 23 | 23 | 23 | 23 | 18 | |
| Slider return rate | mm | 285 | 80 | 70 | 50 | 80 | 55 | 55 | 55 | 55 | 55 | 50 | |
| Laryngeal deep | mm | 320 | 250 | 250 | 320 | 360 | 380 | 380 | 400 | 400 | 450 | 500 | |
| Ejecting stroke speed(mrn/s) | Before and after | mm |
|
|
|
|
| 700 | 700 | 750 | 750 | 750 | 800 |
| around | mm |
|
|
|
|
| 900 | 900 | 900 | 900 | 900 | 1000 | |
| Workbench is apart from the ground height | mm |
|
|
|
|
| 750 | 800 | 850 | 900 | 900 | 900 | |
| Pump name | Pressure compensation variable axial plunger pump | ||||||||||||
| Motor power | Kw | 5.5 | 7.5 | 7.5 | 11 | 15 | 15 | 15 | 15 | 22 | 37 | 2-45 | |
